TL;DR
Revit formulas are expressions attached to family parameters that calculate values automatically. They support arithmetic (+, −, *, /, ^), functions like abs(), sqrt(), and pi(), rounding, trigonometry, conditional logic with IF/AND/OR/NOT, formula-driven text and Yes/No parameters, and CSV lookup tables via size_lookup(). Formulas are written in the Family Types dialog, parameter names are case-sensitive, and units must stay consistent. This guide maps the complete system in 10 chapters.
Key Takeaways
- ✓Formulas live in the Family Types dialog — one formula per parameter, recalculated on every change.
- ✓Parameter names are case-sensitive; units are part of the math and must stay consistent.
- ✓Four capability tiers: arithmetic → conditions → text and visibility control → lookup tables.
- ✓A comparison like Width > 900mm is itself a Yes/No value — the simplest automation there is.
- ✓Nested IFs max out at 3 levels of maintainability; CSV lookup tables take over from there.
- ✓Almost every formula failure is one of six known error patterns — all learnable.
A Revit family without formulas is a drawing that happens to be 3D. A family with formulas is a small machine: change one input and frames resize, hardware upgrades itself, labels rewrite themselves, and parts appear or disappear — all correctly, all at once. This guide is the map of that entire system: what formulas can do, the rules they all obey, and where to learn each part in depth.
What a Revit Formula Is
In the Family Editor, open Family Types. Every parameter has a Formula column — an expression written there calculates the parameter's value instead of accepting manual input:
The moment any referenced parameter changes, every formula that depends on it recalculates, and the geometry follows. That is the whole trick — and the rest is knowing the vocabulary and the rules.
The Three Rules Every Formula Obeys
1 — Names are case-sensitive. A parameter named Width must be written exactly Width. The “can't find parameter” error is almost always a casing or spelling mismatch.
2 — Units participate in the math. Length × Length is an area, Length ÷ Length is a plain number, and every numeric constant in a dimension formula needs its unit: 50mm, not 50.
3 — Types must match. A formula must return the same type as its parameter, and both branches of an IF must return the same type as each other.
The Complete Function Reference
| Category | Functions | Chapter |
|---|---|---|
| Arithmetic | + − * / ^ sqrt() pi() exp() ln() log() | 1 |
| Absolute value | abs() | 2 |
| Rounding | round() roundup() rounddown() | 4 |
| Conditional logic | IF() AND() OR() NOT() | 5 |
| Comparisons | < > = <= >= | 5, 7 |
| Trigonometry | sin() cos() tan() asin() acos() atan() | 8 |
| Table lookup | size_lookup() | 9 |
What Formulas Can Drive
Every parameter type is fair game: lengths and numbers (dimensions, counts, angles), Yes/No parameters that automate geometry visibility and switch nested families, and text parameters that select complete label phrases by condition. The two practical limits: materials cannot be assigned by formula (use the two-geometry visibility workaround), and strings cannot be concatenated.
The 10-Chapter Learning Path
Each chapter below is a full article. Read them in order and you cover the complete system — or jump straight to the problem in front of you:
Where Most People Get Stuck
Three walls, in order: the units wall (“inconsistent units” on the first real formula — Chapter 1 breaks it down), the nesting wall (IF chains that grow until nobody can read them — Chapter 9's lookup tables are the way out), and the debugging wall (a red formula bar and a vague message — Chapter 10's isolation method turns hours of guessing into minutes of process).
